Zavihka GD&T Mill ter GD&T Turn v TBM – Settings pogovornem oknu Kot dodatek pa je dodana tudi opcija preglasitve prepoznave tolerančnega območja (Recognize tolerance range) in prepoznave ISO 286 (Recognize ISO 286 limit and fits) z uporabo značilnosti geometrijskih toleranc. To opcijo najdemo ob odprtju Run pogovornega okna v zavihku CAMWorks TBM / SolidWorks CAM TBM. V CAMWorks 2019 in SOLIDWORKS CAM Professional 2019 je bila dodana opcija določitve obdelovalnih strategij struženja in 2,5-osnih obdelav posameznim značilkam glede na parametre geometrijskih toleranc. Več o TBM si lahko preberete v članku.ĭoločitev obdelovalnih strategij struženja in 2,5-osnih obdelav glede na parametre geometrijskih toleranc (GD&T) z uporabo pogovornega okna TBM Deluje tako, da izkorišča SOLIDWORKS-ove dimenzije, tolerance in kvaliteto površin z ustreznimi oznakami. SOLIDWORKS CAM lets you quickly program individual milled parts and configurations without leaving the SOLIDWORKS 3D CAD environment.CAMWorks vtičnik TBM (”Tolerance Based Machining”-obdelave na osnovi toleranc), ki seveda deluje tudi v SOLIDWORKS CAM, nam olajša izbiro obdelovalnih strategij za naše operacije. Manufacturing tasks that had to wait until a design was complete can now be performed concurrently with the design process leading to better communication and reduced errors. SOLIDWORKS CAM is an add-on to all versions of SOLIDWORKS CAD that lets you prepare your designs for manufacturability earlier in the development cycle.
Knowledge Based Machining is the foundation for streamlining the programming process, learning as you program which frees up your time to focus on the critical areas of the components.
It leverages the rich content in the 3D CAD model to speed up product development and reduce error prone, time consuming, repetitive manual steps in the current development process, like programming CNC machines. SOLIDWORKS® CAM is a fully integrated, Knowledge Based Machining (KBM) technology that allows you to integrate design and manufacturing processes under one system to evaluate designs earlier in the process to avoid unexpected costs and delays in finishing products on time.
